panel led high bay 100W

Parameters

 Input Voltage AC90-305V Color Rendering Index Ra>80
Frequency Range 50~60Hz THD <20%
Power Factor >0.97 LED Reduction Rate 1~3% / 1,000Hrs
Power Efficiency >93% Color Temperature 3000/4000/5000/5700K
LED Working Voltage DC40~48V Working Temperature -30℃~+45℃
Luminous Efficiency ≧110-120 lm/W Power line VDE  3×1.0mm2
Connect wires Brown→L   Blue→N   Yellow or Green→G

features:
anti glare pc design,transmittance is 85%.
small modular permutation design is with higher efficient
lumen efficiency is 110-120lm/W

Heat dissipation feature:
adopting high quality a1070 aaluminum plate as a heatsink,
with good heat conduction and heat dissipation performance,
thus ensuring the life span of the lamp
